Royal® Exposed Sensor Hardwired Urinal Flushometer

Request a Custom Spec

Don't see a variation that matches what you're looking for? You can request a custom spec from us with the exact options you want. Just click the button and fill out the form.

Request a Spec

Downloads

Features

  • Sensor-activated, hardwired urinal flushometer
  • PERMEX™ Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
  • Durability is facilitated with high copper, low zinc brass castings for dezincification resistance
  • Adjustable tailpiece
  • Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass
  • PERMEX synthetic rubber diaphragm with Dual Filtered Fixed Bypass
  • Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
  • Valve shall be in compliance to the applicable sections of ASSE 1037.

Features

Quiet, Exposed, Dual Filtered Diaphragm Assembly, Chrome Plated Urinal

  • Sweat Solder Adapter w/Cover Tube and Cast Wall Flange w/Set Screw
  • OPTIMA® EL-1500 Self-Adaptive Infrared Sensor with Indicator Light
  • Non-Hold-Open Integral Solenoid Operator, Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation
  • High Back Pressure Vacuum Breaker Flush Connection with One- Piece Bottom Hex Coupling Nut, Spud Coupling and Flange for 3⁄4” Top Spud
  • Stop Seat and Vacuum Breaker molded from PERMEX® Rubber Compound for Chloramine Resistance
  • 3⁄4” I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
  • Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection
